| ENGINE |
| Engine |
686cc,Liquid cooled,5-valve,4-stroke,1-cylinder |
| Bore x Stroke |
102mm x 84mm |
| Compression Ratio |
9.2:1 |
| Max. Power |
33.5hp/5000-5500rpm |
| Max Torque |
40.9N.m/5000rpm |
| Fuel Supply |
Electric Fuel Inject (EFI) |
| Ignition |
ECU |
| Starting |
Electric |
| Transmission |
Automatic: L-H-N-R (V-Belt) |
| Drive Train |
Shaft (2WD, 4WD limited slip, 4WD Differential Lock) |
|
| CHASSIS |
| Suspension Front |
Independent double A-arm |
| Suspension Rear |
Independent double A-arm |
| Brakes/Front |
Dual ventilated hydraulic disc |
| Brakes/Rear |
Dual ventilated hydraulic disc |
| Tire Front |
AT26 x 9-12 radial |
| Tire Rear |
AT26 x 10-12 radial |
|
| Dimensions |
| LxWxH |
118.5 x57.5×74(inches) |
| Seat Height |
31.5 inches |
| Wheelbase |
73.7 incehs |
| Ground Clearance |
13 inches |
| Fuel Capatity |
7.66 gal |
| Dry Weight |
1155 lbs |
| Bed Capacity |
400 lbs |
| Towing Capacity |
1500 lbs |
|
OTHER
| Standard Equipment |
Suntop, Foldable Windshield, Aluminum wheels, Storage |
| Color selection |
Red/Blue/Dark Green/Green/VISTA Yellow Camouflage/Black/Silver |
|
