ENGINE
Type 686 cc, Water Cooled, 5-valve, 4-stroke, 1-cylinder
Bore x Stroke 4.02” x 3.30”
Compression Ratio 9.2:1
Max. power 33.5HP/5500-5500rpm
Max. torque 49.0N.m/5000rpm
Carburetion PD42J
Ignition CDI
Start type Electric/Pull start
Transmission L-H-N-R-P
Drive Train Axle
CHASSIS
Suspension/Front Independent double swing arm
Suspension/Rear Independent double swing arm
Brakes/Front Dual ventilated hydraulic disc
Brakes/Rear Ventilated hydraulic disc
Tires/Front AT25×8-12 radial
Tires/Rear AT25×10-12 radial
DIMENSIONS
L x W x H 88.58” x 47.64” x 48.23”
Seat Height 34.25”
Wheelbase 53.74”
Ground Clearance 10.23”
Fuel Capability 4.49Gal/17L
Dry Weight 703 lbs
Loading QTY(20FT/40FT/40HQ) 8/18/27
OTHER
Lighting/Front 12V35W/35Wx2, 12V5Wx2
Lighting/Rear 12V5W/21Wx1
